Boolean satisfiability

A pink title card reads "Logical methods for ∀I, Lecture 5". The A of AI is drawn as the upside-down A of the universal quantifier, ∀, which is the course mascot's name.

Below the card: "Chapter 5: Boolean SAT", and the course address, logicalmethods.ai. At the right, the chapter's opening drawing: a figure consulting a manual labelled "Reasoning: How To".

Heading: "What you'll be able to do". Introduction: "After this lecture and chapter 5, you can:". Five goals follow, each ticked off with a green check mark and tagged on the right with its level in Bloom's revised taxonomy.

One: represent validity and circuit verification as satisfiability problems. Understand and apply. Two: apply the truth-table algorithm to formulas and inferences. Apply. Three: convert propositional formulas into CNF and DNF. Apply. Four: apply formula-based resolution to decide satisfiability. Apply. Five: compare the costs and explanatory outputs of SAT algorithms. Analyse and evaluate.

Closing line: "Read chapter 5 first; exercise sheet 5 comes after the lecture." The mascot ∀I stands at the right wearing a lit lightbulb.

Heading: "Automating the hard work". A green box: in chapter 4 we did it all by hand — list the models, calculate the values, hunt for a countermodel.

Three points follow. Let the machine do it. SAT solving asks one question: can one valuation make all of these true? And two reasoning problems reduce to it.

At the right, the book's drawing of a faulty processor: "2 + 2 =" goes into a chip labelled CPU, and a 5 comes out.

Closing line: "Reduce the problem to SAT, then run an algorithm on it."

Heading: "Satisfiability". A green definition box: a propositional formula is satisfiable iff there is a Boolean valuation under which it is true; unsatisfiable iff there is no such valuation.

Two panels side by side. The blue panel on the left takes SUN ∧ ¬RAIN with v(SUN) = 1 and v(RAIN) = 0, which calculates as 1 AND (NOT 0) = 1. Verdict, in green: satisfiable.

The yellow panel on the right takes SUN ∧ ¬SUN. Both cases fail: 1 AND (NOT 1) = 0, and 0 AND (NOT 0) = 0. Verdict, in red: unsatisfiable.

Closing lines: one valuation settles "satisfiable"; bivalence leaves no third case, so two calculations settle "unsatisfiable" here — in general, every valuation must fail.

Heading: "The SAT problem". A green definition box: a finite set or list of propositional formulas A₁, …, Aₙ is jointly satisfiable iff its conjunction A₁ ∧ … ∧ Aₙ is satisfiable.

Two worked rows. SUN ∨ RAIN together with ¬SUN is satisfiable, by v(SUN) = 0 and v(RAIN) = 1. Adding ¬RAIN leaves no valuation, so the three together are unsatisfiable. A note: each of the three can be satisfied on its own.

A yellow box gives the chapter's definition: a Boolean satisfiability problem, or SAT, asks whether a given propositional formula, or a finite set of propositional formulas, is satisfiable.

Heading: "Reduction 1: circuit verification".

Across the top left, a drawing of the circuit: the wires INPUT₁ and INPUT₂ join and feed a blue box labelled "default-off, AND", whose output feeds a second blue box labelled "default-on, NOT", which feeds a lamp.

Below it, the specification table for NAND, with columns INPUT₁, INPUT₂ and output: 0 0 gives 1, 0 1 gives 1, 1 0 gives 1, and 1 1 gives 0.

On the right, the two formulas. Reading the wiring gives C = ¬(INPUT₁ ∧ INPUT₂). Excluding the row with output 0 gives S = ¬INPUT₁ ∨ ¬INPUT₂. Should be on, versus is on — so we ask where they disagree, and a yellow box holds the question: SAT? ¬(S ↔ C).

Beside it, the book's verification drawing: a figure comparing a circuit against a blueprint and saying "Um......".

Closing lines: satisfiable means that valuation is an input where the circuit is wrong; unsatisfiable means the circuit implements the specification.

Heading: "Reduction 2: deductive validity". A yellow theorem box: an inference A₁, …, Aₙ ∴ B is deductively valid iff (A₁ ∧ … ∧ Aₙ) ∧ ¬B is unsatisfiable.

Two panels. The blue panel on the left takes SUN ∨ RAIN, ¬SUN ∴ RAIN. Premises, then the negated conclusion, give (SUN ∨ RAIN) ∧ ¬SUN ∧ ¬RAIN. No countermodel, so the inference is valid.

The red panel on the right takes SUN ∨ RAIN, SUN ∴ ¬RAIN. We negate the conclusion again, though it starts with ¬, giving (SUN ∨ RAIN) ∧ SUN ∧ ¬¬RAIN. Setting v(SUN) = v(RAIN) = 1 gives a countermodel.

Below, the book's drawing of a coin whose two sides read "EX SAT" and "E Pluribus Unum — In SAT We Trust". Beside it, the closing lines: both reductions hand a SAT solver the same kind of question, so one algorithm answers both.

Heading: "Truth-tables: brute force". A green definition box: a truth-table lists the value of one or more propositional formulas under every assignment to the variables occurring in them.

Four points. For n variables, 2ⁿ assignments. Count from 0 in binary to list them all. Evaluate the formula in each row. And there is no preparation: the formula goes in as it stands.

At the right, the book's three-variable truth-table drawing, with columns SUN, RAIN and WIND and its eight rows numbered 0 to 7, running from 0 0 0 down to 1 1 1.

Closing line: three variables give eight rows; ten give 1024.

Heading: "Evaluating a row". A grey code panel holds the chapter's `evaluate` procedure. It takes a tree and a valuation v. If the tree is a variable, it returns v of that variable. If the operator is ¬, it returns NOT of the value of the child. Otherwise it evaluates the left and right children, then returns AND for ∧, OR for ∨, and XNOR otherwise.

Below the panel, the three clauses it implements: v(¬A) = NOT v(A), v(A ∧ B) = v(A) AND v(B), and v(A ∨ B) = v(A) OR v(B).

At the right, the formula SUN ∨ (¬RAIN ∧ ¬WIND) drawn as a parse tree. The root ∨ has SUN on the left and ∧ on the right; that ∧ has a ¬ over RAIN and a ¬ over WIND. A green arrow runs up the side of the tree, labelled "evaluate upward".

Closing line: every call gets a smaller tree, so evaluation terminates.

Heading: "Searching the table". A grey code panel holds the chapter's `truth_table_sat` procedure: parse the formula, list its variables, and for each binary assignment v, if evaluate returns 1, return "satisfiable" together with v; otherwise, after the last row, return "unsatisfiable".

Below it, the SAT input for the valid inference: (SUN ∨ RAIN) ∧ ¬SUN ∧ ¬RAIN.

At the right, the completed table. Its columns are SUN, RAIN, SUN ∨ RAIN, ¬SUN, ¬RAIN and the conjunction of all three. The four rows read 0 0 0 1 1 0, then 0 1 1 1 0 0, then 1 0 1 0 1 0, then 1 1 1 0 0 0. The last column is boxed in red and labelled "every row 0".

Closing lines: unsatisfiable, so the inference is valid. A 1 would stop the search early; "unsatisfiable" costs every row.

Heading: "A decision procedure". A green definition box: a decision procedure is an algorithm that terminates on every allowed input with the correct yes-or-no answer, and such a problem is decidable.

Three points. Finitely many rows, so the search finishes. A returned valuation makes the formula true. And "unsatisfiable" means every valuation was checked.

A blue box: so SAT is decidable — and the finished table also shows a tautology (all 1s) or a contradiction (all 0s).

Heading: "The cost of brute force". A green box: for n variables and m operators, truth-table search has worst-case time complexity — and below it, in large notation, O(2ⁿ(m + 1)). A note explains: at most 2ⁿ rows, m + 1 steps per row.

A small table gives rows against variables: 3 variables, 8 rows; 10 variables, 1 024 rows; 20 variables, 1 048 576 rows; 40 variables, over a trillion.

At the right, the book's drawing of the exponential curve, with #variables along the bottom and #valuations up the side.

Closing lines: combinatorial explosion — one more variable doubles the work. Can we settle a problem without writing out all those rows? — Sometimes.

Heading: "Normal forms". A green definition box: a literal is a propositional variable or the negation of a propositional variable.

A blue box: a formula is in disjunctive normal form (DNF) iff it is a disjunction of conjunctions of literals. A yellow box: a formula is in conjunctive normal form (CNF) iff it is a conjunction of disjunctive clauses.

At the right, a table with columns formula, DNF? and CNF?. SUN ∨ ¬RAIN: yes, yes. SUN ∧ ¬RAIN: yes, yes. SUN ∨ (RAIN ∧ WIND): yes, no. (SUN ∨ RAIN) ∧ WIND: no, yes. ¬(SUN ∧ RAIN): no, no.

Closing lines: a DNF lists alternative ways to satisfy the formula; a CNF lists requirements that all have to be met. Resolution needs CNF.

Heading: "Rewriting into normal form". A note: each rule replaces a subformula by an equivalent one.

On the left, "push negations inward": r₁ rewrites ¬¬A to A; r₂ rewrites ¬(A ∧ B) to ¬A ∨ ¬B; r₃ rewrites ¬(A ∨ B) to ¬A ∧ ¬B. The result is negation normal form.

On the right, "distribute — for CNF": r₄ rewrites A ∨ (B ∧ C) to (A ∨ B) ∧ (A ∨ C); r₅ rewrites (A ∧ B) ∨ C to (A ∨ C) ∧ (B ∨ C). For DNF, the other way: r₆ rewrites A ∧ (B ∨ C) to (A ∧ B) ∨ (A ∧ C); r₇ rewrites (A ∨ B) ∧ C to (A ∧ C) ∨ (B ∧ C).

A yellow box at the bottom left: first remove every ↔, rewriting (A ↔ B) to (¬A ∨ B) ∧ (¬B ∨ A).

Closing line: the Boolean laws of chapter 4, used in one direction only.

Heading: "The rewriting algorithm". A grey code panel holds the chapter's `normal_form` procedure, which takes a formula and a target. While the formula contains a biconditional, it rewrites the first one. While a negation rewrite applies, it rewrites the first one. While a distribution rewrite applies for the target, it rewrites the first one. Then it returns the formula. Below the panel: each helper rewrites the first matching subformula.

At the right, the worked rewrite towards CNF. Starting from ¬¬SUN ∨ ¬(RAIN ∨ ¬SUN), rule r₁ gives SUN ∨ ¬(RAIN ∨ ¬SUN); rule r₃ gives SUN ∨ (¬RAIN ∧ ¬¬SUN); rule r₁ gives SUN ∨ (¬RAIN ∧ SUN); rule r₄ gives (SUN ∨ ¬RAIN) ∧ (SUN ∨ SUN); and idempotence gives (SUN ∨ ¬RAIN) ∧ SUN, repeated in a green box as the result.

Closing line: every step preserves truth-values, so the result is equivalent.

Heading: "Preprocessing is the expensive part". A green box: distribution copies subformulas, so a compact input can produce exponentially many clauses.

The worked example: (SUN ∧ WARM) ∨ (RAIN ∧ WIND) becomes four clauses — (SUN ∨ RAIN) ∧ (SUN ∨ WIND) ∧ (WARM ∨ RAIN) ∧ (WARM ∨ WIND).

A short tally: 2 pairs, 4 clauses; 3 pairs, 8 clauses; 4 pairs, 16 clauses; n pairs, 2ⁿ clauses, printed in red. At the right, the book's "naive approach" drawing.

Closing line: truth-tables pay at search time, resolution pays before the search starts.

Heading: "The resolution rule". A green definition box: the resolution rule takes two clauses containing complementary literals, removes that pair, and disjoins the remaining literals — their resolvent.

In a blue panel, the general schema, written as an inference: from A ∨ p and ¬p ∨ B, infer A ∨ B. The pivot is p.

At the right, the same rule in two steps. From SUN ∨ RAIN and ¬SUN, infer RAIN. From RAIN and ¬RAIN, infer ⊥ — a refutation.

A yellow box: the empty clause ⊥ is a disjunction with no literals, and its value is 0 under every valuation. Beside it, a red warning: remove only one complementary pair at a time.

Closing line: deriving ⊥ shows no valuation satisfies the starting clauses.

Heading: "Refutation search". A grey code panel holds the chapter's `resolution_sat` procedure: convert the formula to CNF, drop the tautological conjuncts, and start an empty list of checked pairs. While an unchecked pair remains, take the shortest one; for each complementary pivot, resolve and remove repetitions; return "unsatisfiable" if the result is the empty clause; otherwise add it when it is neither a tautology nor already listed. Record the pair as checked. If the loop ends, return "satisfiable".

At the right, two notes. Saturation: every pair gives a tautology or a known clause. And at most 3ⁿ clauses, so the search terminates. The book's little mouse sits above a yellow box stating the theorem: a propositional formula in CNF is unsatisfiable iff resolution can derive the empty clause from it.

Closing lines: ⊥ means unsatisfiable, saturation without it means satisfiable, so exhaustive resolution is a decision procedure too.

Heading: "Tseytin: cheap preprocessing". A green box: give each subformula a fresh name and constrain its value, instead of copying it.

A grey code panel holds the chapter's `tseytin` procedure. It walks the parse tree children first. At a variable it records the variable as its own name; otherwise it takes a fresh variable, records it as the node's name, and adds that node's local clauses. Finally it adds the name of the root and returns the conjunction of all the constraints.

Below the panel: name SUN ∧ RAIN by a fresh u, then add (¬u ∨ SUN) ∧ (¬u ∨ RAIN) ∧ (u ∨ ¬SUN ∨ ¬RAIN).

At the right, a yellow box: two formulas are equisatisfiable iff both are satisfiable or both are not. Below it: one fresh variable and at most four clauses per connective, so the CNF grows linearly.

Heading: "Worked case: verifying the NAND circuit". At the top left, the circuit drawing again: INPUT₁ and INPUT₂ into the default-off AND relay, then the default-on NOT relay, then the lamp. At the top right, the question SAT? ¬(S ↔ C), and the clauses preprocessing keeps: (¬INPUT₁ ∨ ¬INPUT₂) ∧ INPUT₁ ∧ (INPUT₁ ∨ INPUT₂) ∧ INPUT₂.

The blue panel on the left runs the search as one derivation. From ¬INPUT₁ ∨ ¬INPUT₂ and INPUT₁, infer ¬INPUT₂; from that and INPUT₂, infer ⊥. Two steps; the clause INPUT₁ ∨ INPUT₂ is never needed.

The red panel on the right redraws the circuit with the lamp wired straight off the first relay, the second relay greyed out and bypassed by a red wire, so C′ = INPUT₁ ∧ INPUT₂. Saturation arrives with no ⊥, so the formula is satisfiable: both inputs off is an input where it fails.

Closing lines: unsatisfiable on the left means the circuit meets its specification; satisfiable on the right means the valuation names an input where it fails. And finally: two resolution steps decide it — all the work was in preparing the clauses.
